    MODEL

    • S

    S model

    1-2 Person

    S model

    1-2 Person

    Parameter

    • Frame Size

      W985mm x D995mm x H2300mm

    • Inner Frame Size

      W851mm x D950mm x H2166mm

    • Wall

      45mm thick aluminum alloy multi-layer composite WPC hollow

    • Soundproof Glass

      Use 10mm single layer

    • Sound Absorbing Layer

      Noise reduction coefficient NRC=0.91, RoHS standard.

    • Carpet

      10mm velcro textile sound-absorbing carpet

    • Lamps

      4000K, 1600 lumens

    • Socket

      100-240V/50-60Hz and 12V-USB/Type-C; additionally, external connection ports and network cable ports are reserved.

    • Fresh Air System

      The cabin air can be refreshed every 2-3 minutes.

    • Appearance Color

      Black

      White

      Pink

    • Interior Color

      H144

      H234

      H332

      H411

      H518

      H612

      H714

      H837

      H1926

      H2033

      H916

      H1020

      H1105

      H1207

      H1310

      H1439

      H1545

      H1647

      H1741

      H1843

    • WPC composite wall panels for office pods

      Multi-layer Composite Wall

      The 45mm-thick polymer wood-plastic composite (WPC) hollow-core wall system complies with international standards for noise reduction performance, features a B1-class flame retardancy rating, and utilizes a PVC film surface finish.

    • Soundproof Glass

      It uses 10mm tempered glass, which is explosion-proof and fire-resistant. The entire structure is sealed with double-layer sound insulation film and surrounding sound insulation sealing strips, effectively improving sound insulation and vibration reduction.

    • Status-sensitive Smart Light

      The system intelligently senses human presence; when someone is working inside, ventilation, lights, and power automatically turn on, and when someone leaves, these functions automatically turn off. It saves energy and is convenient and fast.

    • Ventilation System

      Features a multi-layered sound barrier design and an upward-inward, downward-outward circulating airflow. The PD labyrinth-type low-noise fresh air system reduces sound transmission between the interior and exterior of the pod, allowing for a complete air exchange every 2 minutes.  The design achieves a sound insulation rating of RW+Ctr 30dB.

    • Lighting System

      4000K color temperature LED lights, luminaire efficacy: 80-90 lm/w, 19W flat panel light source, providing continuous and stable sufficient lighting inside the pod, reducing eye strain.  Three-color controllable lighting allows for easy switching between work and rest modes.

    • Power System

      It is compatible with 100-240V/50-60Hz and 12V-USB, Type-C power supply, and is equipped with an international socket, three-way switch and USB interface inside the cabin. It also has reserved external connection port and network cable port to support multi-functional application scenarios.

    • Door Handle System

      Features a rust-proof alloy silent door lock for easy installation. The silent design effectively enhances sound insulation and sealing, preventing sound and dust from entering.
